Lowrance 3G Broadband Radar

SKU: 000-10418-001

The Lowrance Broadband 3G Radar for HDS Series fish finders and chartplotters goes more than the extra nautical mile, now with 30% more range! Featuring Frequency Modulated Continuous Wave (FMCW) technology, Lowrance Broadband Radar innovation delivers superior target detection and viewing separation, ease of operation, and higher level of navigational peace-of-mind. With zero radiation hazard, it’s the safest choice for more boats, including fishing, sports/cruising and sail boats.
Find a dealer

Share this

Product details

Lowrance Broadband 3G Radar uses high-efficiency, low emission solid-state technology to deliver clear and precise location of shorelines, navigation buoys, floating debris, current weather conditions, marinas and other structure, along with boats ranging from large ocean- going vessels to small kayaks. With a low power draw, Broadband 3G radar produces less emissions than a mobile phone making it safe for everyone on board. Lowrance Broadband 3G Radar is the perfect navigation accessory for any HDS unit.

Key features

  • Instant On: Solid-state technology produces an immediate, accurate on-screen image, without the lengthy warm-up delay of magnetron pulse radars.
  • Low Power Consumption: Ideal for boats of any size – sail, cruise or fish.
  • Automatic Clarity: Proven automatic harbor/marina and offshore modes.
  • MARPA Target Tracking: Track up to 10 targets. Requires a heading sensor.*
  • Radar/Chart Overlay: Merges radar with cartography in a detail-rich display.*
  • Crystal-Clear Image: Fantastic for tight maneuvers in marinas or in conditions of limited visibility.
  • Quick Installation: No reason to open the dome, no tune or zero-mile adjustment, and no radar-licensed technician required.
  • Safe: Extremely Low Emissions. Safer than any other radar currently on the market and emitting less radiation than a mobile phone so it can be mounted anywhere.
  • High-Speed Mode: Select 36 RPM for almost instant updating at less than 2 nm.
  • Dual Guard Zones: Protect yourself from more angles.

What's in the box?

  • Ethernet Adapter Cable 2M - 5P Male to RJ45 Female


+35° C (95° F), 95% RH
Compass Safe
0.7 m (2.3 ft) Min
Max Wind Speed
100 knots
Warranty Period
2 years
Max Range, scale
24 nm
Rotation speed
24/36 rpm +/-10% mode dependent
Dimensions Diameter
489 mm (19.3”)
Dimensions H x W x D
489 mm x 280 mm (19.3" x 11”)
Beam width
5.2° +/- 10% (-3dB width)
Min Range, scale
50 m (200 ft
7.4 kg (16.31 lbs)
Supply Voltage
9V to 31.2Vdc (12/24 Volt systems)
Mounting Type
Bolts 4 x M8x30 - 304 stainless steel
Approvals Compliance
CE, FCC (ID: RAY3G4G), IC: 4697A-3G4G
Radar Technology
Frequency Modulated Continuous Wave (FMCW)
Radar Modes
Head Up, North Up
Sart Racon
Operating Temperature Range
Operating Temperature: -25° to +55°C (-13° to +130°F)
Power Consumption typical
Operating: 18W (Typ.) @ 13.8Vdc, Standby: 2W (Typ.) @ 13.8Vdc ~ 150mA
See Radar Controller
PC Connectivity
NMEA 2000 Connectivity
Via Optional RI-10
Ethernet Ports
Via RJ45 Adapter cable (000-0127-56) 1 x 100 Mbit 5 pin yellow
